2-STROKE Diesel Engine
The bearing wear monitoring and alarm system
The bearing wear monitoring and alarm system of this product has been installed more than 1,000 sets in domestic machine factories so far, and we also provide for retrofitting installation on the delivered ships. The system's distance sensors, temperature sensors
and corresponding water in oil sensors can monitor in real time and dynamically reflect the running status of the main bearing on the display device, provide pre-alarm to avoid serious bearing wear issue.
The BDMS provided by Dr. E. Horn GmbH & Co. KG has been recognized by MAN since 2006. It has adopted the product as the standard configuration of its new engines, and it is recommended to install BDMS on all MAN engines currently in use. And through the approval of many classification societies, can provide the corresponding approval certificate (BV/LR/ABS/DNV-GL)
Main bearing temperature sensor type (optional)
This sensor is optional and can be ordered separately. It can measure the temperature of the oil overflowing from the main bearing. The miniaturized flat design allows the sensor to be mounted on the main bearing seat close to the bearing bush. This sensor can be easily installed on the main bearing seat with the help of an internal permanent magnet.
